Intel Xeon E5-2680 V4 Processor
Original price was: AED650.AED250Current price is: AED250.
- Intel Xeon E5-2680 V4 Processor
- Max Turbo Frequency 3.30 GHz
- Processor Base Frequency 2.40 GHz
- Total Cores 14
- Total Threads 28
- Cache 33 MB L3 Cache
- Max # of UPI Links 2
- TDP 120 W
- Quantity Available.
- Extended Warranty Available
Estimated delivery:3 days
Essentials
| Product Collection |
Product Collection Intel® Xeon® Processor E5 v4 Family Code Name Products formerly Broadwell Vertical Segment Server Processor Number E5-2680V4 Lithography 14 nm |
Processor
| CPU Information |
Intel® Xeon® Processor E5-2680 v4 35M Cache, 2.40 GHz - Core Count - 14 Number of threads - 28 Base clock frequency - 2.4GHz Maximum turbo frequency - 3.3GHz Cache - 33MB Lithography - 14nm TDP - 120W Socket - LGA3647 Maximum RAM size - 1.5TB Number of PCI Express lines - 48 PCI Express Version - 3.0 |
CPU Specifications
| Supported Processors |
Total Cores: 14 Total Threads: 28 Max Turbo Frequency: 3.30 GHz Intel® Turbo Boost Technology 2.0 Frequency: 3.30 GHz Processor Base Frequency: 2.40 GHz Cache: 35 MB Intel® Smart Cache Bus Speed: 9.6 GT/s # of QPI Links: 2 TDP: 120 W |
Supplemental Information
| Embedded Options Available |
Marketing Status Launched Launch Date Q1'16 Servicing Status End of Servicing Updates End of Servicing Updates Date Thursday, June 30, 2022 Embedded Options Available Yes Use Conditions Server/Enterprise |
Memory Specifications
| Memory Specifications |
Max Memory Size (dependent on memory type) 1.5 TB Memory Types DDR4 1600/1866/2133/2400 Max # of Memory Channels 4 Max Memory Bandwidth 76.8 GB/s Physical Address Extensions 46-bit ECC Memory Supported ‡ Yes |
Expansion Options
| Scalability |
Scalability 2S PCI Express Revision 3.0 PCI Express Configurations: x4, x8, x16 Max # of PCI Express Lanes 40 |
Package Specifications
| Sockets Supported |
Sockets Supported FCLGA2011 Max CPU Configuration 2 TCASE 86°C Package Size 45mm x 52.5mm |
Advanced Technologies
| Intel® Optane™ Memory Supported ‡ |
Intel® Turbo Boost Technology ‡ 2.0 Intel® Hyper-Threading Technology ‡ Yes Intel® Transactional Synchronization Extensions Yes Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® AVX2 Idle States Yes Enhanced Intel Speed Step® Technology Yes Intel® Demand Based Switching Yes Thermal Monitoring Technologies Yes Intel® Flex Memory Access No Intel® Identity Protection Technology ‡ No |
Security & Reliability
| Software/security |
Intel vPro® Eligibility ‡ Intel vPro® Platform Intel® AES New Instructions Yes Secure Key Yes Intel® OS Guard Yes Intel® Trusted Execution Technology ‡ Yes Execute Disable Bit ‡ Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes |
