ThinkSystem SR650 Rack Server
Original price was: AED8,400.00.AED5,500.00Current price is: AED5,500.00.
- ThinkSystem SR650 Rack Server (Refurbished)
- Dual Intel® Xeon® Gold 6138 Processor Family
- RAM DDR4 32GB 2666MHz
- SAS Hot Plug 2 x 600GB 2.5-inch
- Dual Power Supply 500 Watt
- Extended Warranty Available
Estimated delivery:1 - 2 days
HP ProLiant DL380 Gen10 Server Price List:
-
ThinkSystem SR650 Rack Server (Basic) AED/-499916 Core / 32 vCPU ( Dual Intel Xeon Silver 4110) | Memory 64GB/DDR4 | Hard Drive 2 x 600 GB 2.5/3.5-inch SAS HDD
- ThinkSystem SR650 Rack Server (Standard) AED/-5999
40 Core / 80 vCPU ( Dual Intel Xeon Gold 6138) | Memory 64GB/DDR4 | Hard Drive 2 x 512 GB 2.5-inch SATA SSD
- ThinkSystem SR650 Rack Server (Reliable) AED/-6499
40 Core / 80 vCPU ( Dual Intel Xeon Gold 6138) | Memory 128GB/DDR4 | Hard Drive 2 x 512 GB 2.5-inch SATA SSD
- ThinkSystem SR650 Rack Server (Professional) AED/-6999
40 Core / 80 vCPU ( Dual Intel Xeon Gold 6138) | Memory 256GB/DDR4 | Hard Drive 2 x 1TB 2.5-inch SATA SSD
- ThinkSystem SR650 Rack Server (Advanced) AED/-8999
40 Core / 80 vCPU ( Dual Intel Xeon Gold 6138) | Memory 512GB/DDR4 | Hard Drive 2 x 2TB 2.5-inch SATA SSD
Specification
| Brand | IBM |
| Model | Lenovo ThinkSystem SR650 Rack Server |
| Part Number | ThinkSystem SR650 |
Product Type
| Product type | Rack Server |
Form Factor
| Form Factor | 2U |
Processor
| CPU Information |
Intel® Xeon® Gold 6138 Processor (27.5M Cache- 2.00 GHz) Essentials Product Collection Intel® Xeon® Scalable Processors Code Name Products formerly Skylake Vertical Segment Server Processor Number 6138 Lithography 14 nm Use Conditions Server/Enterprise CPU Specifications Total Cores 20 Total Threads 40 Max Turbo Frequency 3.70 GHz Processor Base Frequency 2.00 GHz Cache 27.5 MB L3 Cache Max # of UPI Links 3 TDP 125 W Supplemental Information Marketing Status Launched Launch Date Q3'17 Servicing Status ESU Notification Issued End of Servicing Updates Date Sunday | December 31 | 2023 End of Interactive Support Date Sunday | December 31 | 2023 Embedded Options Available Yes Datasheet View now Product Brief View now Additional Information View now Memory Specifications Max Memory Size (dependent on memory type) 768 GB Memory Types DDR4-2666 Maximum Memory Speed 2666 MHz Max # of Memory Channels 6 ECC Memory Supported ‡ Yes Expansion Options Scalability S4S PCI Express Revision 3 Max # of PCI Express Lanes 48 Package Specifications Sockets Supported FCLGA3647 TCASE 86°C Package Size 76.0mm x 56.5mm Advanced Technologies Intel® Optane™ Memory Supported ‡ No Intel® Speed Shift Technology Yes Intel® Turbo Boost Max Technology 3.0 ‡ No Intel® Turbo Boost Technology ‡ 2 Intel® Hyper-Threading Technology ‡ Yes Intel® Transactional Synchronization Extensions Yes Intel® 64 ‡ Yes Instruction Set Extensions Intel® AVX-512 # of AVX-512 FMA Units 2 Enhanced Intel SpeedStep® Technology Yes Intel® Volume Management Device (VMD) Yes Security & Reliability Intel vPro® Eligibility ‡ Intel vPro® Platform Intel® AES New Instructions Yes Intel® Trusted Execution Technology ‡ Yes Execute Disable Bit ‡ Yes Intel® Run Sure Technology Yes Mode-based Execute Control (MBEC) Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes |
CPU Specifications
| Supported Processors |
Supported Processors Platinum 8280 Processor 2.7 GHz 28 38.50 MB 205W 3 @ 10.4 GT/s 2933 MT/s 1TB Platinum 8280L Processor 2.7 GHz 28 38.50 MB 205W 3 @ 10.4 GT/s 2933 MT/s 4.5TB Platinum 8280M Processor 2.7 GHz 28 38.50 MB 205W 3 @ 10.4 GT/s 2933 MT/s 2TB Platinum 8276 Processor 2.2 GHz 28 38.50 MB 165W 3 @ 10.4 GT/s 2933 MT/s 1TB Platinum 8276L Processor 2.2 GHz 28 38.50 MB 165W 3 @ 10.4 GT/s 2933 MT/s 4.5TB Platinum 8276M Processor 2.2 GHz 28 38.50 MB 165W 3 @ 10.4 GT/s 2933 MT/s 2TB Platinum 8270 Processor 2.7 GHz 26 35.75 MB 205W 3 @ 10.4 GT/s 2933 MT/s 1TB Platinum 8268 Processor 2.9 GHz 24 35.75 MB 205W 3 @ 10.4 GT/s 2933 MT/s 1TB Platinum 8260 Processor 2.4 GHz 24 35.75 MB 165W 3 @ 10.4 GT/s 2933 MT/s 1TB Platinum 8260L Processor 2.4 GHz 24 35.75 MB 165W 3 @ 10.4 GT/s 2933 MT/s 4.5TB Platinum 8260M Processor 2.4 GHz 24 35.75 MB 165W 3 @ 10.4 GT/s 2933 MT/s 2TB Platinum 8260Y Processor 2.4 GHz 24/20 /16 35.75 MB 165W 3 @ 10.4 GT/s 2933 MT/s 1TB Platinum 8256 Processor 3.8 GHz 4 16.50 MB 105W 3 @ 10.4 GT/s 2933 MT/s 1TB Platinum 8253 Processor 2.2 GHz 16 22.00 MB 125W 3 @ 10.4 GT/s 2933 MT/s 1TB 1st Generation Intel® Xeon® Scalable Processor Family Platinum Processors Platinum 8180M Processor 2.5 GHz 28 38.50 MB 205W 3 @ 10.4 GT/s 2666 MT/s 1.5TB Platinum 8180 Processor 2.5 GHz 28 38.50 MB 205W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8176 Processor 2.1 GHz 28 38.50 MB 165W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8170 Processor 2.1 GHz 26 35.75 MB 165W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8168 Processor 2.7 GHz 24 33.00 MB 205W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8165 Processor 2.3 GHz 24 33.00 MB 205W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8164 Processor 2.0 GHz 26 35.75 MB 150W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8160 Processor 2.1 GHz 24 33.00 MB 150W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8158 Processor 3.0 GHz 12 24.75 MB 150W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8156 Processor 3.6 GHz 4 16.50 MB 105W 3 @ 10.4 GT/s 2666 MT/s 768GB Platinum 8153 Processor 2.0 GHz 16 22.00 MB 125W 3 @ 10.4 GT/s 2666 MT/s 768GB |
Memory
| Installed Memory | RAM DDR4 32GB 2666MHz |
| Memory Type |
For 1st Generation Intel Xeon Scalable Processor (Intel Xeon SP Gen 1): Slots: 24 memory module slots Minimum: 8 GB Maximum: 768 GB using registered DIMMs (RDIMMs) 1.5 TB using load-reduced DIMMs (LRDIMMs) 3 TB using three-dimensional stack registered DIMMs (3DS RDIMMs) Type (depending on the model): TruDDR4 2666, single-rank or dual-rank, 8 GB/16 GB/32 GB RDIMM TruDDR4 2666, quad-rank, 64 GB LRDIMM TruDDR4 2666, octa-rank, 128 GB 3DS RDIMM For 2nd Generation Intel Xeon Scalable Processor (Intel Xeon SP Gen 2): Slots: 24 DIMM slots Minimum: 8 GB Maximum: 1.5 TB using RDIMMs 3 TB using 3DS RDIMMs 6 TB using DC Persistent Memory Module (DCPMM) and RDIMMs/3DS RDIMMs in Memory Mode Type (depending on the model): TruDDR4 2666, single-rank or dual-rank, 16 GB/32 GB RDIMM TruDDR4 2933, single-rank or dual-rank, 8 GB/16 GB/32 GB/64 GB RDIMM TruDDR4 2933, single-rank or dual-rank, 16 GB/32 GB/64 GB Performance+ RDIMM TruDDR4 2666, quad-rank, 64 GB 3DS RDIMM TruDDR4 2933, quad-rank, 128 GB 3DS RDIMM TruDDR4 2933, quad-rank, 128 GB Performance+ 3DS RDIMM 128 GB/256 GB/512 GB DCPMM DCPMM installation rules: DCPMMs are not supported if any GPU is installed. DCPMMs only support the following server models: eight 3.5-inch-drive bays, eight 2.5-inch-drive bays, or sixteen 2.5- inch-drive bays. The 256 GB and 512 GB DCPMMs only support server model with eight 2.5-inch-drive bays. If the processors with TDP equal to 200 watts or 205 watts are installed, DCPMMs are supported only when the following requirements are met: Two power supplies are installed. For server models with sixteen 2.5-inch and eight 3.5-inch drive bays, the operating temperature is equal to or less than 30°C. No Mellanox ConnectX-6, Innova-2 FPGA, or PCIe NVMe add-in-card (AIC) installed. |
Storage and drives
| Installed Hard Disk | 2 x 600GB |
| Device Type | SAS Hot Plug |
| Storage Option |
Internal drives The supported drives vary by models. Up to eight 3.5-inch hot-swap SAS/SATA drives Up to twelve 3.5-inch hot-swap SAS/SATA drives Up to twelve 3.5-inch hot-swap SAS/SATA/NVMe drives (NVMe drives are supported only in drive bays 8–11) Up to eight 2.5-inch hot-swap SAS/SATA drives Up to eight 2.5-inch hot-swap SAS/SATA/NVMe drives (NVMe drives are supported only in drive bays 4–7) Up to sixteen 2.5-inch hot-swap SAS/SATA drives Up to sixteen 2.5-inch hot-swap SAS/SATA/NVMe drives (NVMe drives are supported in drive bays 4–7 and bays 12–15) Up to sixteen 2.5-inch NVMe drives (NVMe drives are supported in drive bays 0–15) Up to sixteen 2.5-inch NVMe drives with eight SAS/SATA drives (NVMe drives are supported in drive bays 0–15) Up to twenty 2.5-inch NVMe drives (NVMe drives are supported in drive bays 0–19) Up to twenty-four 2.5-inch hot-swap SAS/SATA drives Up to twenty-four 2.5-inch hot-swap SAS/SATA/NVMe drives (NVMe drives are supported in drive bays 4–7, bays 12–15, and bays 20–23) Up to twenty-four 2.5-inch NVMe drives (NVMe drives are supported in drive bays 0–23) Up to two 3.5-inch hot-swap SAS/SATA drives in the rear Up to two M.2 drives |
| Storage Controller |
Onboard SATA ports with software RAID support (Intel VROC SATA RAID, formerly known as Intel RSTe) NOTE VROC is not supported with the VMware ESXi yet. Onboard NVMe ports with software RAID support (Intel VROC NVMe RAID) VROC Intel-SSD-Only (also known as Intel VROC standard): supports RAID levels 0, 1, 5, and 10 with Intel NVMe drives only VROC Premium: supports RAID levels 0, 1, 5, and 10 with non-Intel NVMe drives An HBA 430-8e or 430-16e SAS/SATA adapter that support JBOD mode but does not support RAID An HBA 430-8i or 430-16i SAS/SATA adapter that support JBOD mode but does not support RAID An HBA 440-8e SAS/SATA adapter that support JBOD mode but does not support RAID An HBA 440-8i or 440-16i SAS/SATA adapter that support JBOD mode but does not support RAID An HBA 4350-8i or 4350-16i SAS/SATA adapter that support JBOD mode but does not support RAID A RAID 530-8i SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, 10, and 50 A RAID 530-16i SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, and 10 A RAID 540-8i or 540-16i SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, and 10 A RAID 730-8i 1GB Cache SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, 10, and 50 A RAID 730-8i 2GB Cache SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, 6, 10, 50, and 60 A RAID 730-8i 4GB Flash SAS/SATA adapter with CacheCade (for some models only) that supports JBOD mode and RAID levels 0, 1, 5, 6, 10, 50, and 60 A RAID 930-8e SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, 6, 10, 50, and 60 A RAID 930-8i, 930-16i, or 930-24i SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, 6, 10, 50, and 60 A RAID 940-8e 4GB SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, 6, 10, 50, and 60 A RAID 940-8i, 940-16i, 940-32i, or 940-8e 4GB SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, 6, 10, 50, and 60 A RAID 5350-8i SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, and 10 A RAID 9350-8i 2GB or 9350-16i 4GB SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1, 5, 6, 10, 50 and 60 |
Graphics
| Supported Display Adapter |
Your server supports the following GPUs or processing adapters: Full-height, full-length, double-slot GPUs or processing adapters: AMD MI25, AMD V340, NVIDIA® M10, NVIDIA M60, NVIDIA P40, NVIDIA P100, NVIDIA P6000, NVIDIA RTX5000, NVIDIA RTX A6000, NVIDIA V100, NVIDIA V100S, NVIDIA A100, A16, and A30. Full-height, full-length, single-slot GPU: NVIDIA P4000 , NVIDIA RTX4000, and Cambricon MLU100-C3 Full-height, half-length, single-slot GPU: NVIDIA V100, NVIDIA A10 Half-height, half-length, single-slot GPU: NVIDIA A2 Low-profile, half-length, single-slot GPUs: NVIDIA P4, NVIDIA P600, and NVIDIA P620, NVIDIA T4, and Cambricon MLU270-S4 |
Ports/slots/bays
| Expansion Slots |
One PCIe slot on the system board One RAID adapter slot on the system board Two riser card slots on the system board Two or three PCIe slots on the riser card |
| Input/output ports |
Front panel: One VGA connector (available on some models) One XClarity Controller USB connector One USB 3.0 connector Rear panel: One VGA connector One XClarity Controller network connector One serial port (available on some models) Two USB 3.0 connectors Two or four Ethernet connectors on the LOM adapter (available on some models) |
Environmental specifications
| Temperature |
Air temperature: Operating: ASHRAE class A2: 10–35°C (50–95°F); when the altitude exceeds 900 m (2953 ft), the maximum ambient temperature value decreases by 1°C (1.8°F) with every 300 m (984 ft) of altitude increase. ASHRAE class A3: 5–40°C (41–104°F); when the altitude exceeds 900 m (2953 ft), the maximum ambient temperature value decreases by 1°C (1.8°F) with every 175 m (574 ft) of altitude increase. ASHRAE class A4: 5–45°C (41–113°F); when the altitude exceeds 900 m (2953 ft), the maximum ambient temperature value decreases by 1°C (1.8°F) with every 125 m (410 ft) of altitude increase. Server off: 5–45°C (41–113°F) Shipping or storage: -40–60°C (-40–140°F) Maximum altitude: 3050 m (10 000 ft) Shipping or storage: 8%–90% Particulate contamination |
| Humidity |
Relative humidity (non-condensing): Operating: ASHRAE class A2: 8%–80%; maximum dew point: 21°C (70°F) ASHRAE class A3: 8%–85%; maximum dew point: 24°C (75°F) ASHRAE class A4: 8%–90%; maximum dew point: 24°C (75°F) |
Power
| Power Supply |
One or two hot-swap power supplies for redundancy support 550-watt ac 80 PLUS Platinum 750-watt ac 80 PLUS Platinum 750-watt ac 80 PLUS Titanium 1100-watt ac 80 PLUS Platinum 1600-watt ac 80 PLUS Platinum |
Physical specifications
| dimensions ( H x W x D) |
Height: 86.5 mm (3.4 inches) Width: With rack latches: 482.0 mm (19.0 inches) Without rack latches: 444.6 mm (17.5 inches) Depth: 763.7 mm (30.1 inches) |
| Weight | Up to 32.0 kg (70.6 lb), depending on the server configuration |
OPERATING SYSTEM
| Pre Install Os |
OS Provided: Type Non Supported and certified operating systems: Microsoft Windows Server VMware ESXi Red Hat Enterprise Linux SUSE Linux Enterprise Server |
SERVICE & SUPPORT
| Warranty | Limited 03-month warranty |
Server Stock provides free delivery within the UAE for every order that is above AED 500. If the value of the order is below AED 500, we do collect a nominal delivery charge of AED 30. Server Stock delivers the products within the duration 1 to 2 working days. Deliveries will only be processed during business working days, and please note that public holidays and Friday will be counted as non-working days. The products which are “In Stock” on the website will be shipped on the same day if the order is placed before 3 pm. If we receive the order after 5 pm, we will ship it on the next day based on the product’s availability. Same day express delivery also available for Dubai, Sharjah and Ajman. Express delivery charges will be 150AED. We accept COD (Cash on Delivery) and Bank Transfers for orders placed from within the UAE. Bank Transfer should be done for the orders placed from the locations that are outside of the UAE. Please ensure whether the shipping providers delivers the servers from UAE to your destination before placing the order.
Server Stock offers Three- month warranty for all of our Refurbished products that is covering the most parts, with exceptions for burn and physical damage. Server Stock also offers flexible extendable warranty options. for example, Each 3 months extended warranty you need to add 5% extra, it means if you want any product with one year warranty then you need to add 15% extra amount in total price. You can avail free of cost repairs or replacement if needed during the warranty period for the Refurbished products. Actual warranty starts on the day when you purchase the product from us.
Related products
Free Shipping On order over 500AED
Money Back Guaranteed in 15 days return.
Store Pickup Collect Your Order In-Store .
100% Genuine product.
24/7 Tech Support online available.
Three-Months Warranty.
Refurbished Grade "A" Condition.
Refurbished Condition?
Details
What To Expect? The item has been slightly used | It may have minimal scratches on top. An original product that is lightly used and tested by experts for 100% functionality. Item will be delivered in generic packaging with all compatible accessories.
